    Nema 8 Planetary Gearbox Stepper Motor With Max.Ratio 1 369 and Bipolar Configuration

    Ask Lasest Price
    Brand Name : Umot
    Model Number : 20HS1405/6401
    Price : $39.48/pieces 5-99 pieces
    • Product Details
    • Company Profile

    Nema 8 Planetary Gearbox Stepper Motor With Max.Ratio 1 369 and Bipolar Configuration

    Nema 8 Planetary Gearbox Stepper Motor With Max.Ratio 1 369 and Bipolar Configuration
    Nema 8 Planetary Gearbox Stepper Motor With Max.Ratio 1 369 and Bipolar Configuration
    Precision High-end Upgrade With Nema 8, Nema 11, Nema14, Nema 17, Nema 23, Nema 24
    Stepper motor: low noise , low vibration , firm and durable.
    Increase torque at low speed.
    Reduction ratio: 1:3.7, 1:5.2, 1:14, 1:19, 1:27, 1:51, 1:71, 1:100, 1:139, 1:189, 1:264, 1:369
    And 48 hours delivery , in stock
    Product name
    Nema 8 Planetary Gearbox Stepper Motor
    Warranty
    3months-1year
    Place of Origin
    China
    Brand Name
    Umot
    Model Number
    20HS1405/6401
    Phase
    2 Phase
    Type
    Hybrid
    Certification
    CCC, ce, ISO
    Motor length
    20mmX20mm
    Load range
    0.6N.m-2.0N.m
    Weight
    0.06/0.1kg
    Color
    Silver
    Reduction ratio
    3.7:1/5.2:1/14:1/19:1/27:1/51:1/71:1/100:1/139:1/189:1/264:1/369:1
    Rated Voltage
    3.25/4.40V
    Rated Current
    0.5/0.8A
    Efficiency
    66%-90%
